UV Spotcure Powerarc UV100

4,325.00€ exc VAT

The PowerArc UV100 is the perfect unit for rapid, controlled UV curing. This low cost, yet powerful unit minimizes IR and maximizes UV output for quick curing and low risk of component overheating. It can be used in manual applications or mounted for automated processes. The adjustable lamp intensity peaks at a powerful 7W/cm² at 365 nm.

Available on backorder

SKU: UV-A121-032 Category: Tags: ,

Description

UV Spotcure Powerarc UV100

Features

Specifications
• Compact, reliable and easy movement
• Easy operation – precision control
• Durable construction
• Low maintenance,
• Long lamp life results,
• Higher throughput
• Fast and easy lamp replacement
• Working hours UV lamp counter		 • Lamp: 100 W mercury short arc lamp
• Lamp life: 1000 hours warranteed
• Peak intensity: 7 W/cm² @ 365 nm peak
• Output: 100 W/cm² (250 nm – 500 nm)
• Light delivery: F 5 mm x 1M toxic-free liquid light guide (single)
• Warm up: 2 minutes
• Dimensions: 16 cm H x 33 cm W x 27 cm D
• Weight: 9.5 kg
• Power Supply: 230V, 50 H

Specification

Weight 10 kg
Dimensions 45 × 35 × 25 cm
